21
DECK MOUNTING
* Not illustrated
ITEM
PART NO
1
2216042
2 *
2216041
3
455000387
4
176147-01
5 *
176147-02
6
38404-01
7
118047-04
8
001490226
9
009079430
10
001594170
11
842000044
12
2213006
13
W178154
14
456110595
15
452200134
16
452101510
17
MBF1921.7
17 *
002190180
18 *
MBF1922.7
19
456110503
20
MBF2200
*
MBG5349
*
450382
*
002993013
*
451488
21
W176061.7
22
W176059.7
23 *
W176060.7
24
178045.7
25
MBG5638
27
001399121
28
456110503
28*
452100019
29
A904247
30
64166-15
31
W178153-01
32
MBF1871a.7
33 *
MBF1874a.7
34
451030730
35
450020281
36
W173010
37
450392
38
2216037
All manuals and user guides at all-guides.com
DESCRIPTION
Wldmnt-Hook Rear LH
Wldmnt-Hook Rear RH
Pin-Tension 1/4 X 1-1/4
Wldmt-hook Frnt LH
Wldmt-hook Frnt RH
Grip,Cntrl Lvr
S Bshg Flip-lok.50 Id
'R' Clip
Pin-Clevis 3/8 X 2.46
Washer
Lubricator-1/4" Str
Pin-Pivot
Cylndr-wing Sq Port
(Use Bushing 178154-01 Qty 2)
Scrw-hex 3/8-16 X 3/4
Lockwshr-3/8 X .683 X .094
Wshr-3/8 X 1-1/2 X .104
Wldmt-arm Rear LH
Bush,1"X1.125"X0.75"
Wldmt-arm Rear Rh
Scrw-hex 1/4-20 X 5/8
Wldmt-pin
Fitted From Under Arm
(Not As Shown)
Clamp Ring Wshr
Nut-hex M16 Nyloc
Lubricator-M6 Str
Pin-spirol 8 X 20
Wldmt-Swing Arm Rear
Wldmt-Swing Arm LF
Wldmt-Swing Arm RF
Spring-wing Deck
Brkt-front Roller
Nut-hex 1/4-20 Nyloc
Scrw-hex 1/4-20 X 5/8
Wshr-1/4 X 5/8 X .064
Rubber Roller
Shoulder Bolt
Connector-chn Link
Wldmt-Arm Front LH
Wldmt-Arm Front RH
Bolt-hex 1/2-20 X 3-1/2
Nut-hex 1/2-20 Thin
Shaft-Cutter Deck
Wshr-M12 X 24 X 2.7
Wldmt-Tank Support
960 FRONTLINE
PARTS MANUAL
LIST OF PARTS
QTY
REMARKS
1
1
2
1
1
2
4
2
2
8
6
4
2
(Use Seal Kit 4129601 With 84)
4
4
6
1
(Includes Item 83)
2
1
(Includes Item 83)
6
4
4
Used Item 20
4
Used Item 20
4
Used Item 20
4
Used Item 20
2
1
1
2
2
4
4
4
4
4
4
1
(Includes Item 84)
1
(Includes Item 84)
2
4
2
24
2
Parts-59
