7A WHEEL MOTOR - FRONT
* Not illustrated
ITEM PART NO
008007240
001 A808966
002 A808967
010 A808968
N/A
N/A
015 A808969
025 A808970
027 N/A
040 A808971
041 N/A
042 N/A
043 N/A
044 N/A
045 N/A
047 N/A
048 N/A
050 N/A
051 N/A
052 N/A
053 N/A
054 N/A
055 N/A
056 N/A
057 N/A
059 N/A
065 A808972
066 N/A
067 N/A
070 A808973
071 N/A
072 N/A
073 N/A
074 N/A
075 N/A
076 N/A
077 N/A
078 N/A
079 N/A
All manuals and user guides at all-guides.com
DESCRIPTION
Wheel Motor
Seal kit
Seal kit
Cylinder-block Assy.
• Piston sub-assy.CI.0
• Piston sub-assy.CI.10
Repair kit.
Cam Assy.
• O-ring.
Valving cover assy.
• Valving cover part.
• Screw.
• Seal washer.
• Screw.
• O-ring.
• Valving.
• Seal kit.
• Plug.
• O-ring.
• Spring.
• Valve spool.
• Washer.
• Snap ring.
• Spring.
• O-ring.
• Pin.
Cover plate.
• Screw.
• Sealing ring.
Bearing support assy.
• Bearing support.
• Radial lip seal.
• Roller bearing.
• Roller bearing.
• Set of shims.
• Thrust ring.
• Snap ring
• Lip Seal
• Deflector
960 FRONTLINE
PARTS MANUAL
LIST OF PARTS
QTY REMARKS
2
1
1
1
1
1
Part of seal kit 001 & 002
1
Part of seal kit 001 & 002
Part of seal kit 001 & 002
Part of seal kit 002
Part of seal kit 001 & 002
1
1
Part of seal kit 001 & 002
Part of seal kit 001 & 002
Part of seal kit 001 & 002
Parts-21
