9 HYDRAULIC VALVES
* Not illustrated
ITEM PART NO
1 4116078
3 2218227
4 2212049
5 2212092
6 4125581
7 450411
10 450038
11 450391
12 450379
13 450213
14 001090341
15 2218225
16 450379
17 450040
18 450454
19 001090341
All manuals and user guides at all-guides.com
DESCRIPTION
4wd Manifold Valve
Hyd Valve For Wing Deck
Bracket-valve Mtg
Bracket-rh Valve Mtg
Screw - Cap Head M8x100
Washer - Spring M8
Bolt-hex M10 X 80
Wshr-M10 X 21 X 2.2
Nut-hex M10 Nyloc
Scrw-hex M10 X 20
Bolt, M10 X 160
Hyd Valve For Front Deck
Nut-hex M10 Nyloc
Bolt-hex M10 X 90
Nut-hex M10 Verbus Ripp
Bolt, M10 X 160
960 FRONTLINE
PARTS MANUAL
LIST OF PARTS
QTY REMARKS
1
2
1
1
3
3
4
12
8
4
1
1
2
2
2
1
Parts-29
