Textron RANSOMES JACOBSEN Frontline 960 Manuel De Maintenance page 143

4 FRAME - FRONT
* Not illustrated
ITEM PART NO
1 MBF2423
2 2208058.07
3 4125140
4 4125219
5 4125141
6 2216084
7 4125824
8 4125825
9 2212082
10 2212064
11 4125225
MBF1988
002989380
12 450191
13 450390
14 148034-08
15 450241
16 450392
17 450380
18 450193
19 001594010
20 450378
21 W148034-01
22 450214
23 450391
24 450379
25 64061-04
26 W143036a
27 W138040
28 001393400
29 MBG3817
30 64152-21
31 48228-05
32 001399121
33 456110498
34 2218084
35 452200176
36 2212245
37 523126
38 001393010
39 450453
40 MBA5289A
41 450192
42 2720289
All manuals and user guides at all-guides.com
DESCRIPTION
Plate-Seat Mtg
Hinge-seat Plate
Wldmt-Tower
Wldmt-RH Frame Rail
Wldmt-LH Frame Rail
Wlmnt-Bulkhead
Fender-LH
Fender-RH
Back-Plate Fender
Cover-Access
Wldmt-Front Axle
Plate W/A
Trim Seal
Scrw-hex M8 X 20
Wshr-m8 X 17 X 1.8
Insulated Grommet
Screw-hex M12 X 30
Wshr-m12 X 24 X 2.7
Nut-hex M12 Nyloc
Scrw-hex M8 X 30
Wshr-.328 X .75 X 14 Ga
Nut-hex M8 Nyloc
Insul Grommet 1" I/D
Scrw-hex M10 X 25
Wshr-m10 X 21 X 2.2
Nut-hex M10 Nyloc
Roll Pin-1/8x3/4
Rod-support
Clip-hood Rod
Nut-hex #6-32 Keps
Brkt-rod Clip
6-32x1/2lg Rd Hd Sc
Clip-cable,Insulated
Nut-hex 1/4-20 Nyloc
Scrw-hex 1/4-20 X 1/2
Grommet
Lockwshr-1/2 X .873 X .125
Bracket-deck Stop
Bumper-rubber
Nut-hex 5/16-18 Whiz
Nut-hex M8 Verbus Ripp
Wshr-8.5 X 25.5 X 3
Scrw-hex M8 X 25
Assy-m12 Bolt W/Lanyard
960 FRONTLINE
PARTS MANUAL
LIST OF PARTS
QTY REMARKS
1
2
1
1
1
1
1
1 (Not Shown)
2
1
1
1
AR
13
8
1
16
16
14
3
18
17
1
4
8
4
2
1
1
4
1
4
1
1
1
1
2
2
2
2
4
4
4
2
Parts-11
