COUPLES
F
BOULONNERIE STANDARD (AMERICAN
NATIONAL STANDARD FASTENERS)
DIMENSION UNITES
6–32 in-lb (Nm)
in-lb (Nm)
8–32
10–24 in-lb (Nm)
in-lb (Nm)
10–32
in-lb (Nm)
12–24
1/4–20 in-lb (Nm)
in-lb (Nm)
1/4–28
5/16–18 in-lb (Nm)
5/16–24
in-lb (Nm)
3/8–16
ft-lb (Nm)
3/8–24
ft-lb (Nm)
7/16–14
ft-lb (Nm)
7/16–20
ft-lb (Nm)
1/2–13
ft-lb (Nm)
1/2–20
ft-lb (Nm)
9/16–12
ft-lb (Nm)
9/16–18
ft-lb (Nm)
5/8–11
ft-lb (Nm)
5/8–18
ft-lb (Nm)
3/4–10
ft-lb (Nm)
3/4–16
ft-lb (Nm)
7/8–14
ft-lb (Nm)
DIMENSION UNITES
Nm (in-lb)
M4
M5 Nm (in-lb)
Nm (in-lb)
M6
Nm (in-lb)
M8
Nm (ft-lb)
M10
M12 Nm (ft-lb)
Nm (ft-lb)
M14
CLASSE 5 CLASSE 8
20 (2.3) –
24 (2.7) 30 (3.4)
35 (4.0) 45 (5.1)
40 (4.5) 50 (5.7)
50 (5.7) 65 (7.3)
95 (10.7) 125 (14.1)
95 (10.7) 150 (17.0)
200 (22.6) 270 (30.5)
240 (27.1) 300 (33.9)
30 (40.7) 40 (54.2)
35 (47.5) 45 (61.0)
50 (67.8) 65 (88.1)
55 (74.6) 70 (94.9)
75 (101.7) 100 (135.6)
85 (115.3) 110 (149.2)
105 (142.4) 135 (183.1)
115 (155.9) 150 (203.4)
150 (203.4) 195 (264.4)
160 (217.0) 210 (284.8)
170 (230.5) 220 (298.3)
175 (237.3) 225 (305.1)
300 (406.8) 400 (542.4)
BOULONNERIE METRIQUE
4.8 5.8
1.2 (11) 1.7 (15)
2.5 (22) 3.2 (28)
4.3 (38) 5.7 (50)
10.5 (93) 13.6 (120)
21.7 (16) 27.1 (20)
36.6 (27) 47.5 (35)
58.3 (43) 76.4 (55)
RANSOMES Frontline 951 Plus
MANUEL D'UTILISATION
Couples recommandés (± 10%) pour ces
types d'attaches. Utiliser ces spécifications
sauf indication contraire.
Ransomes utilise des boulons qualite 5 en
standard (qualite commerciale minimum).
Ne pas utiliser des boulons de qualite
inferieure sauf indication contraire.
COUPLE DU BOULON DE LAME: 95 Nm
ECROUS DE ROUES: 75-88 Nm
8.8 10.9
2.9 (26) 4.1 (36)
5.8 (51) 8.1 (72)
9.9 (88) 14.0 (124)
24.4 (216) 33.9 (300)
47.5 (35) 66.4 (49)
82.7 (61) 116.6 (86)
131.5 (97) 184.4 (136)
Boulonnerie
non critique
12.9
dans
l'aluminium
5.0 (44) 2.0 (18)
9.7 (86) 4.0 (35)
16.5 (146) 6.8 (60)
40.7 (360) 17.0 (150)
81.4 (60) 33.9 (25)
139.7 (103) 61.0 (45)
219.7 (162) 94.9 (70)
F-45
