COMPONENT REVIEW

1 M OTO R
Het type motor hangt af van het type van machine (zie "Technical data" on
page 35 ).
2 M A N O M E T E R
On the manometer one can read the pressure.
3 B U R N E R
The type of burner depends on the type of cleaner. The 'green burner' is a
burner that makes a higher efficiency. The burner provides hot water. The
temperature of the water is adjustable. The burner is double- walled. The
outside wall is air cooled by the ventilator lateral on the burner chamber. On
top of the burner one can find the burner mouth. The water supply and outlet
are both situated at the bottom of the burner. The temperature of the water is
adjustable till 100°C.
Lime scale deposits while working at higher temperatures
The hardness of the water is possible expressed in French degrees (°F) or
German degrees (°D). The difference is noticeable in the following equation:
1 ° F = 0.56 ° D. For example, water having a hardness of 40 ° F has a German
hardness of 40 x 0.56 = 22.4 ° D. See the in your area prescribed hardness of
drinking water. Hard water can cause problems by means of lime scale from
30°F or 17°D. When hardened water is now warmed / heated / or being pumped
(or when hard water comes in contact with air), this can cause calcification.
Hard water is caused mainly by the presence of two components: calcium
and magnesium. So the harder the water, the more chances on lime scale!
When cleaning with high temperatures (or at using heated water) , you obtain
thus faster calcification in case of a low hardness! This can therefore result in
loss of energy efficiency, higher energy consumption and reduced capacity
of water supply (including calcium deposits on the burner coil and other water
connection parts).
We, DIBO NV, therefore recommend to decalcify the machines with a burner
preventive additionally and after use of hot water rinse adequate with cold
water (if possible) to ensure optimum performance of the machine!
4 H I G H P R E S S U R E P U M P
The type of high pressure pump depends on the type of machine
(see "Technical data" on page 35 ).
5 S E C U R I T Y
The machine is equipped with pressure, flow and temperature security.
The electric motor is equipped with an oil and temperature security.
6 T R A I L E R ( N OT W I T H A S K I D V E R S I O N )
The machine is build on a trailer, equipped with an single-walled isolated
housing witch can be opened on three sides. Option: the trailer can be
equipped with an overrun brake.
7 WAT E R TA N K A N D D I R T Y WAT E R TA N K
The water tank is an reservoir that is assembled between the water system (tap)
and the high pressure pump. The water tank prevents that there may appear
pressure impulses in the water system. Pressure impulses appears by switching
on and off the spray jet. The water tank prevents under all circumstances that
there penetrates chemicals in the water system. The tank has also an overflow
for draining the overage water. There's also a dirty water tank present to
suck- in the used dirty water. The dirty water tank has a level measurement +
surveillance and a safety valve. This safety valve opens at a too large under
pressure in the recycling tank. The level measurement of both tanks can be
read on the screen of the operation panel. This happens by pushing the reset
button during 5 seconds. The dirty water tank has also a gate valve below the
trailer to drain the used water (see also point 22).
8 WAT E R F I LT E R
The water supply is cleaned with the water filter.
