2. Press the "30" key to set the next adjustment cycle for an inverted valve, or press "40" to exit. When you
press "30," the display changes to:
3. To confirm that the next adjustment cycle is for an inverted valve, press "80"; or press "40" to cancel and
exit. When you press "80," the display changes to:
Proceed as usual, following the steps in Valve Adjustment: Implanted Valve Mode. At the end of the adjustment
cycle, the program unit returns to the normal adjustment cycle.

Appendix E: Clinical Study Summary

In a clinical study consisting of 172 subjects, 159 subjects had an x-ray taken with a blinded core lab consensus
reading. In these 159 subjects, 103 (65%) of the subjects received an "Adjustment Complete" message and
56 (35%) of the subjects received a "Repeat Adjustment" message. Of the "Adjustment Complete" patients,
55% received an "Adjustment Complete" message after the first attempt at reprogramming and 99% received
the "Adjustment Complete" message within the 5 attempts established in the study design.
CODFR10065zz10svn.indd 11 CODFR10065zz10svn.indd 11
ADJUST INVERTED
VALVE?
PLEASE CONFIRM
80 = YES 40 = NO
IMPLANTED VALVE
INVERTED VALVE
PLEASE SELECT
PRESSURE
11
