13.2 Factory setting
104
All manuals and user guides at all-guides.com
Further settings
Configuring the sensor source in the feed
In the "Diagnostics and measured values" menu
1. "Heating/cooling quantity measurement"
2. "Sensor feed temperature"
3. Select "Select sensor source".
Configuring the sensor source in the return
In the "Diagnostics and measured values" menu
1. "Heating/cooling quantity measurement"
2. "Sensor return temperature"
3. Select "Select sensor source".
Potential sensor source options:
ƒ
Analogue input AI 2 (only active sensor)
ƒ
Analogue input AI 3 (PT1000 only active sensor)
ƒ
Analogue input AI 4 (PT1000 only active sensor)
ƒ
CIF module
Configuring the sensor position in the feed
1. "Heating/cooling quantity measurement"
2. "Sensor feed temperature"
3. Select "Select sensor position".
Select "Feed" or "Return" as the sensor positions.
Configuring the sensor position in the return
1. "Heating/cooling quantity measurement"
2. "Sensor return temperature"
3. Select "Select sensor position".
Select "Feed" or "Return" as the sensor positions.
Potential sensor position options:
ƒ
Analogue input AI 2 (only active sensor)
ƒ
Analogue input AI 3 (PT1000 only active sensor)
ƒ
Analogue input AI 4 (PT1000 only active sensor)
ƒ
BMS (Building management systems)
ƒ
Feed
ƒ
Return
ƒ
Primary circuit 1
ƒ
Primary circuit 2
ƒ
Secondary circuit 1
ƒ
Secondary circuit 2
The pump can be reset to factory settings.
In the "Restore and reset" menu, select
1. "Factory setting"
2. "Restore factory setting"
3. and "Confirm factory setting" one after the other.
NOTICE
Resetting pump settings to factory settings replaces the current pump settings!
, select
, select
