en
8.4 Differential pressure sensor con-
nection
8.5 Wilo Net connection
8.6 Turn of the display
92
All manuals and user guides at all-guides.com
Electrical connection
NOTICE
The control is designed as a SELV (Safe Extra Low Voltage) circuit. In this way, the
(internal) supply fulfils the requirements for safe separation of the supply. GND is
not connected to PE.
NOTICE
The pump can be switched on and off without intervention from the operator. This
can be done, for example, using the control function, by external BMS connection or
also by the function EXT. Off.
If pumps are delivered with a differential pressure sensor fitted, it is connected to ana-
logue input Al 1 at the factory.
If the differential pressure sensor is connected on-site, carry out the cable assignment
as follows:
Cable Colour
Brown
1
Black
2
Blue
3
Table 12: Connection; differential pressure sensor cable
NOTICE
For a twin-head pump or Y-pipe installation, connect the differential pressure
sensor to the main pump! The measuring points of the differential pressure sensor
must be on the suction and discharge side of the double-pump system in the com-
mon collector pipe. See chapter "Twin-head pump installation/Y-pipe installation".
Wilo Net is a Wilo system bus used for establishing communication between Wilo
products:
ƒ
Two single pumps as a twin-head pump in the Y-piece or one twin-head pump in a
twin-head pump housing
ƒ
Several pumps used with Multi-Flow Adaptation control mode
ƒ
Wilo-Smart Gateway and pump
For details on connection, see the detailed instructions at www.wilo.com!
NOTICE
For Stratos GIGA2.0-D, the Wilo Net cable for twin-head pump communication is
factory-fitted to both electronic modules.
CAUTION
If the graphic display is not fixed properly and the electronic module is not installed
correctly, protection class IP55 is no longer ensured.
• Ensure that no gaskets are damaged!
Terminal Function
+24 V +24 V
In1 Signal
GND Earth
WILO SE 2021-02
