Fig. 3: Updating the firmware
• If you select B
LUETOOTH
Bluetooth not possible!):
A list of all available devices appears.
• Select IQ MODULE CM-RC-01.
• Click the C button.
ONNECT
• Enter Bluetooth password. Factory setting from firm-
ware version 2.6.58.00 on: "8670", previous ver-
sions: "2"
The C menu appears with the M
ONFIGURATION
window. The compressor module is now connected to
the mobile device.
5.1 Configuration via BEST SOFTWARE
Information
For further information on operating parameter
monitoring, electrical connection and communic-
ation via BEST SOFTWARE, see Technical In-
formation KT-230.
Configuration via BEST SOFTWARE (see figure 4,
page 16)
At least the following parameters need to be set / selec-
ted in the C
ONFIGURATION
• Compressor type.
• Refrigerants.
• Motor starter function.
• Serial number of the compressor.
Depending on the equipment installed, the following
parameters may have to be enabled:
• Type of start unloading.
16
(firmware update via
S
AIN
menu:
• Additional fan.
• CRII capacity control and the number of capacity
regulators installed.
• Monitoring of application limits.
• Low pressure and high pressure switches.
Once you have set all parameters, transfer the settings
to the device.
ETUP
Fig. 4: Transferring user settings to the compressor module
