If no additional extension kits are mounted:
• Proceed with the other electrical connections on the
CM-RC-01 (see chapter Further electrical connec-
tions on the CM-RC-01, page 10).
• Mount the cable holders, lay the cables and close
the cable ties (see chapter Mounting the cable hold-
ers and laying the cables, page 10).
• Screw the protective earth conductor onto the ter-
minal box cover and attach the cover to the module
14
housing (see chapter Closing the module housing,
page 10).
4.3 Mounting the "Additional fan" extension kit
Information
For details, see Technical Information KT-140.
• Loosen the relevant screws on the cylinder
head, fit the fixing plates and screw tight
(tightening torque 80 Nm).
• Use the enclosed screws and nuts (see small
figure) to fasten the fan feet.
