Mounting the washer
Drainage washer
Fig. 13g
Fig. 13h
Note:
Pay attention to the correct position of the washer.
The PTFE tube (5) with the washer (18) can be mounted optionally on the vertical glass sets.
It serves for filling the evaporator flask when there is a vacuum in the glass set.
Solvent can be sucked through the PTFE tube into the evaporator flask by opening the stopcock (4).

Hose system

1
2 3 4
5
RV 10.4002 Vacuum valve
RV 10.5001 Water valve Hose clamp Hose clamp Silicon hose (inner dia. 5 mm)
(
Optional)
for silicone hose for vacuum hose
for water
pos. 5, 6 & 7 pos. 8
6 7 9
8
Silicon hose (inner dia. 6 mm) Silicon hose (inner dia. 7 mm)
Vacuum hose
Connector
for water for water for water valve
10 10 10
10 10 10
RV 10.2_20 RV 10.3_30 RV 10.4_40 RV 10.5_50
RV 10.1_10 RV 10.6_60
Fig. 14a
50
