Chapter 9
Fig. 7:

Pin assignment

and connection
diagram
Tab. 11:
Pin assignment
for the
IN3000 Direct
safety switches
84
© SICK AG • Industrial Safety Systems • Germany • All rights reserved
Technical specifications
9.2 Pin assignment
Pin Wire color
1 BN
2 WH
3 BU
4 BK
Operating instructions
+24 V DC
IN1
GND
IN2
Function
L+ (24 V DC)
OUT1
L– (GND)
OUT2
8014173/YIJ3/2016-04-18
Subject to change without notice
IN3000 Direct
