SICK IN3000 Direct Mode D'emploi page 47

Operating instructions
IN3000 Direct
8014173/YIJ3/2016-04-18
Subject to change without notice
Contents
Contents
1 About this document..........................49
1.1 Function of this document..................... 49
1.2 Target group ........................................... 49
1.3 Depth of information.............................. 50
1.4 Scope...................................................... 50
1.5 Abbreviations used ................................ 51
1.6 Symbols used......................................... 52
2 On safety ..............................................53
2.1 Qualified safety personnel..................... 53
2.2 Applications of the safety
switches.................................................. 54
2.3 Correct use ............................................. 55
2.4 General safety notes and
protective measures .............................. 55
3 Product description ............................57
3.1 IN3000 Direct series safety
switches.................................................. 57
3.2 Features and principle of
operation ................................................ 57
3.3 Enable zone and safe switch off
distance.................................................. 59
3.4 LED displays ........................................... 62
3.5 Displays in operating mode ................... 63
3.6 Signal behavior ...................................... 64
3.7 Response times of the safety
switch ..................................................... 66
3.7.1 Response times of the IN30-
E0407K, IN30-E0305K and
IN30-E0306K safety switches.............. 66
3.7.2 Response time of the IN30-
E0208K safety switch............................ 66
