Operating instructions
IN3000 Direct
12
Annex
8014173/YIJ3/2016-04-18
Subject to change without notice
Annex
12.1 List of tables
Tab. 1: Enable zone and safe switch off
distance IN30-E0407K ............................. 60
Tab. 2: Enable zone and safe switch off
distance IN30-E0305K ............................. 60
Tab. 3: Enable zone and safe switch off
distance IN30-E0306K ............................. 61
Tab. 4: Enable zone and safe switch off
distance IN30-E0208K ............................. 61
Tab. 5: LED displays in operating mode................ 63
Tab. 6: Output parameters for the IN3000
Direct safety switch ................................... 64
Tab. 7: Response times of the IN30-E0407K,
IN30-E0305K and IN30-E0306K safety
switches ..................................................... 66
Tab. 8: Response times of the IN30-E0208K
safety switch .............................................. 66
Tab. 9: Error rectification ....................................... 77
Tab. 10: Technical specifications ............................ 80
Tab. 11: Pin assignment for the IN3000 Direct
safety switches .......................................... 84
Tab. 12: Ordering information for the sensors........ 87
Tab. 13: Ordering information for the accessories . 87
© SICK AG • Industrial Safety Systems • Germany • All rights reserved
Chapter 12
89
