Chapter 3
Tab. 6:
Output parame-
ters for the
IN3000 Direct
safety switch
64
© SICK AG • Industrial Safety Systems • Germany • All rights reserved
Product description
3.6

Signal behavior

The safe state is the switched off state of an output
(electrically isolated state: Logical "0").
If the actuating element is in the enable zone and
there is no sensor error, both output stages are
enabled (logical "1").
The output parameters are compatible with the
parameters for the input in compliance with
EN 61131-2 type 1 or 2:
Logical "1" @ 15 V DC
@ 11 V DC
Logical "0"
C
If the actuating element is outside the enable zone,
the outputs are switched off (logical "0").
2 ... 15 mA
15 ... 30 mA
5 V DC Residual current 0.2 mA
