Timer ON / OFF

The air conditioning unit on / off time can be set in advance
from a minimum of 15 minutes up to a maximum 24 hours,
starting from the current time.
To carry out programming, switch on the unit with the remote
control.
Set the required operating mode and room temperature.
Then select TIMER ON or TIMER OFF using the "TIMER
selection buttons". Set the required on / off time using the
"Time setting" buttons (15 minutes – 24 hours) and confirm
with TIMER ON or TIMER OFF.
Press the relevant timer button again to deactivate the timer
function.

Reset

Restores the remote control to its factory settings Set-up sym-
bol flashes. The settings on the remote control are reset to
"air circulation", fan level low, no timer.

Resend

The most recent settings are transmitted again.

Setup

Press the set-up button until the set-up icon flashes. Air con-
ditioning selection currently in use. Settings are reset to "air
circulation", fan level low, no timer.

Maintenance

Located on the front side of the unit is a fluff filter (n) and a
particle filter (p) for cleaning the air in the room.
p
n
The fluff filter (n) must be cleaned at regular intervals, at least
twice a year, and replaced if necessary (part no. 40090-64600).
We recommend that the particle filter (p) be replaced annually
at the start of the season (part no. 40090-58100).
To change the filters, disconnect cold air ducts beforehand.
Pull fluff filter (n) forward slightly at recesses at upper edge
and remove from above. Then withdraw particle filter (p) from
the front.
The arrows printed on the particle filter (p) must point
towards the unit when the filter is installed – these indi-
cate the recirculated air flow direction. The device must
never be operated without the filter. Without a filter the
evaporator will become dirty, which in turn will impair the
performance of the device!
The condensation water drain is located beneath the floor of
the vehicle. In order to allow the condensation to drain away
freely, check whether the drain is free of dirt, leaves and the
like at regular intervals. If this is not done, there is a risk
of condensation water penetrating into the vehicle!

Troubleshooting

Is the motor home / caravan 230 V power supply lead
connected, and are the fuses and circuit breakers OK?
Fault Cause / Action
Unit not cooling – Defrost in progress / wait until
defrosting is completed.
– The temperature set on the re-
mote control has been reached /
set the temperature on the
remote control lower than the
room temperature.
Unit not heating – Defrost in progress (outside
temperature between 4 °C and
7 °C) / set fan lower.
– Outside temperature
below 4 °C.
Unit cooling insuffi- – Filter dirty / change filter.
ciently or not at all
– External airways dirty, blocked /
unblock airways.
Moisture on the cold air – High air humidity / close win-
pipes dows and doors and set the fan
level to high.
Remote control not – Check remote control batteries /
working replace batteries if necessary.
Unit not respond- – Check for obstructions be-
ing to remote control tween remote control and IR
commands receiver / remove obstructions if
necessary.
– Is the remote control paired
with the IR receiver / pair re-
mote control to the IR receiver.
If this does not solve the problem, please contact the Truma
Service.
17
