Setting of the end positions

4. Setting of the end positions

4.1. Delivery status

In the SELVE delivery status no end positions or transmitters are programmed into
the radio motor! In this state, the motor can be operated in deadman's operation only.
Safety functions are deactivated at delivery and will only become active after both end
positions are set.
In delivery status the SE Plus-RC is in semi-automatic programming mode. This will be
signalized by a short up and down movement when connected to mains.

4.2. Setup functions

The end positions setting of a SELVE radio motor is possible via:
• the setting switch for radio motors (item no. 290109) or with
• any standard switch (only in semi-automatic mode) or with
• any standard commeo or iveo transmitter.

4.3. Mechanic requirements

The operation of the SE Plus-RC as roller shutter drive is possible by using safety
springs or blocking springs. When using the SE Plus-RC as awning motor the awning
fabric will often be connected directly with the fabric shaft.
Caution:
There is no automatic setting of the lower end limit when using the SE Plus-RC. The
lower end limit has always to be run-up to or also set.
Caution:
When setting in semi-automatic and manual setting mode, a fixed upper end limit has
to exist if this end limit has to be recognized from the drive automatically.

4.4. Selection table for settings

Setup-mode/end positions in
operation
Semi-automatic setup-mode
bottom position, top stop/release*
Manual setup-mode
bottom position, top stop/release*
Manual setup-mode
bottom position, top position
* Both setting procedures are leading to the same result: bottom position: point, top position: limit
stop/relief
Setting switch commeo radio
4.5.1. (page 47) 5.2.1. (page 53)
4.5.2. (page 48) 5.2.2. (page 54)
4.5.3. (page 49) 5.2.3. (page 55)
45
GB
iveo radio
6.1.1. (page 60)
GB
6.1.2. (page 61)
6.1.3. (page 62)
