GB commeo initial operation/Setting by radio
Note for settings under point 5.2.: The motor must be selected for this setting with
a transmitter in SELECT mode (Status LED flashes slowly in orange). After completing
the setting, the motor is still selected (see point 5.).
5.2.4. Programming/deleting transmitters
To program or deprogram a transmitter, select the desired channel and push the PROG
button for 1 second. The status LED lights up green to indicate that the transmitter has
been programmed. A red light means that the transmitter has been deprogrammed.
1 s
5.2.5. Delete transmitter table in the receiver
To delete the transmitter table in the receiver, push the PROG button on the transmitter
for 6 seconds. All transmitters programmed in the receiver are deleted. The receiver is
still programmed in the transmitter. The programmed receiver has been cancelled in
the transmitter.
Note: This causes an error message if there are any more programmed
receivers!
If this receiver in operating mode moves over a transmitter which is still
programmed, the transmitter will no longer receive a response and will ack-
6 s
nowledge this with an error message.
5.2.6. Reset the receiver to the factory setting
To reset a receiver to factory settings, push the PROG button on the transmitter for
9 seconds. All settings are reset to factory settings. There are no transmitters and end
positions saved in the motor anymore! The programmed receiver has been cancelled
in the transmitter.
Note: This causes an error message if there are any more programmed
receivers!
If this receiver in operating mode moves over a transmitter which is still
programmed, the transmitter will no longer receive a response and will ack-
9 s
nowledge this with an error message.
5.2.7. CONFIGURATION mode (only for authorised qualified personnel)
To set a receiver to the CONFIGURATION mode, push the STOP and PROG buttons
at the same time for 3 seconds.
+
3 s
Concurrent pushing of the STOP and PROG buttons for 3 seconds permits leaving the
CONFIGURATION mode prematurely.
Status LED transmitter = green
Status LED transmitter = red
Note: Only for authorised qualified personnel!
Changes on the configuration adjustment can lead to a damage
of the construction since security systems may be switched off.
transmitter programmed
transmitter deleted
56
