Installation instructions, only for experts

3.4. Mounting of the lighting

When installing the lighting it must be ensured that these are installed as far as
possible from the sauna heater (preferably in the opposite corner).
CAUTION!
The sauna light must conform to the 'IPX4' protection class.
CAUTION!
The sauna light must be designed for an ambient temperature of 140°C.
TIP!
You can connect the cabin light to the power unit of the Wave.com4
sauna control unit.

3.5. Mounting of the operating unit (WC4-B-D/H/W/S)

Use a commercially available Ø 70 mm hole cutter to mount the operating unit.
The internal display is affixed on the cabin wall at the end of the cable duct.
Interior view
Abb. 8: mounting of the operating unit
p. 14/42
