Instructions for use for the user
„HUM" = humid operation:
•
Standard humidity operation:
Standard humidity operation offers the utilisation of a humidity sensor
(regulation according to per cent humidity).
TIP!
Standard humidity operation can be executed with the optional compo-
nents WC4-H-PCB, (WC4-H-F2) and WC4-H-H.
•
Timed humidity:
Timed humidity offers no utilisation of a humidity sensor (regulation
according to per cent humidity). You can select humidity steps (0 to 99)
in this operating mode. The timed humidity is activated by a D-sensor
(Dummy sensor).
TIP!
Timed humidity can be executed with the optional components WC4-H-
PCB, WC4-H-F2 and the D-sensor.
CAUTION!
To this end, please observe the humidity - temperature characteristic
curve below (EN60335-2-53 compliant).
100
90
80
70
60
50
40
30
20
10
0
0
10
Figure 9: humidity - temperature characteristic curve
20
30
40
50
60
70
80
Temp
p. 19/42
90
100
110
EN
