Installation instructions, only for experts

3. Assembly of the components

3.1. Assembly of the power unit

Preferably mount the Wave.com4 power unit on the cabin roof, where all wires
logically converge.
• Open the casing by loosening the screw connection of the lid.
• Remove the lid of the Wave.com4 power unit.
• You can affix the Wave.com4 power unit to the subfloor at the 4 corners
of the chassis.
exterior view
Figure 2: connection of Wave.com4 power unit
p. 9/42
EN
