Functions in service mode

8.4. Group separation

A group is an assembly of several drives/receivers that can be controlled by one trans-
mitter/channel. This transmitter is deleted after the end of the group separation. During
group separation, each drive/receiver will only once move randomly for 3 seconds
within a period of time of approx. 2 minutes. Stopping the drive with any transmitter
will teach this transmitter into the respective drive.
First press the STOP button and then the UP and DOWN buttons as well. Keep all three
buttons depressed for 9 seconds, in order to start the group separation (wait until the
transmitter control light flashes three times). The drive indicates activation of group
separation by a short run. Then each drive will move randomly for 3 seconds within a
period of about 2 minutes. Within the 3-second time slot, stop the movement of the
motor using the STOP button on the transmitter to be programmed. Then the transmit-
ter is taught in, and the drive has left the group separation mode.
Fuse/Hirschmann plug
3 sec. 3 sec. 3 sec.
Window 1 Window 2
3 sec. 3 sec.
Transmitter
1
If the drives are still moving together, repeat the procedure for the drives affected.
If you did not teach in a transmitter through the STOP button and no other transmitter
is taught in, you may teach in this transmitter again by pressing the UP and DOWN
buttons at the same time and then pressing the PROG button.
➧
Window 3
3 sec.
Transmitter Transmitter
2
✓
Every drive moves randomly only for
3 seconds within about 2 minutes.
The drive in question must be
stopped by the selected trans mitter
during the movement.
3
39
GB
9 sec.
➧
