Commissioning
5.2 Removing the transport lock
26 / 73
6
5
Fig. 24: Unpacking 5675
1 Hexagon nut
2 Flat
3 Device feet
4 Castor
5 Metal rail
6 Wooden beams
1. Remove the packaging.
2. Remove the wooden beam (
3. Attach the metal rails (
4. Slide the wooden beam (
5. Place an open-end spanner (size 10 mm) on the surfaces (
3 ) upwards as far as possible.
the device feet (
6. Carefully roll the centrifuge off the wooden pallet over the metal rails
( 5 ).
7. Push the centrifuge to its installation location.
8. Place the open-end spanner (size 10 mm) on the flats (
3 ) down until the castors ( 4 ) are no longer in contact
the device feet (
with the ground.
9. Align the centrifuge so it is horizontal by turning the device feet (
10. Turn the hexagon nuts (
provided (size 19 mm) and screw them in to lock the device feet in
3 ).
position (
Personnel:
■
Trained user
Rev.: 24 / 01.2024
3
6 ).
5 ) to the wooden pallet using two nails each.
6 ) under the metal rails ( 5 ) to support them.
1 ) upwards using the open-end spanner
1
2
4 3
2 ) and turn
2 ) and turn
3 ).
AB5650en
