4 Technical data
Control unit
Maximum power (kW) at the switch output (if cos φ = 1)
Nominal current range
Dimensions (LxWxD), mm
Potential-free contact
Required fuse protection
Residual current device (RCD) required
Pump
Information\pump type
Weight
Power P1/P2
Speed
Operating voltage
Rated current
max. pumping capacity
max. pumping height
max. temperature (perma-
nent) of pumped material
Protection rating
Protection class
Operating mode
4.1 Dimensions, volume
Pumping volume [l]
Tank volume [l]
26 / 112
All manuals and user guides at all-guides.com
Weight
Operating voltage
Standby power
Battery specification
Working temperature
Protection rating
Protection class
Connection type
SPF 1300
10 kg
1500W/910W
2600 rpm
230V; 50Hz
6.4A
32 m /h
3
9.2m
35°
IP68 (3m)
I
S3 - 15%
approx. 20
approx. 50
Lifting station/Installation and operating instructions
1.8 kW
3 - 8 A
0.5 kg
140x150x75
230V / 50Hz
2.5 W
max. 42 V DC / 0.5 A
1x 9V 6LR61
0 - 40°C
IP 54
I
C16 A single pole
30 mA
Schuko earthed safety plug
Fig. 1: Pumping capacity and height
