Accessories

Note
• Select accessories from the catalogue (è www.festo.com/catalogue).
Designation
ELFA-RF
Oil gun
Oil cartridge
Oil
1) (Spare parts catalogue è www.festo.com/spareparts)
Tab. 4
10

Fault clearance

Malfunction Possible cause
Squeaking noises, Tension
vibrations or the
axis is not running
smoothly
Roller bearing guide defective
Lack of lubrication on the
roller guide
Wear on guide or band
reverser
Slide does not Loads too high
move
Mounting screws for
payload too long
Slide travels The proximity sensors do
beyond the end not react
position
Cover band has Wear on band reverser
waves
Oil leak between Oil accumulator completely
profile housing saturated
and cover
Tab. 5
Festo – ELFA-RF – 1412NH English
Part number/type
1)
8041022/AZTP-S-L
8041024/AZLO-H1-C-10
Elkalub VP916, Chemie-Technik, Vöhringen
Remedy
Install the ELFA free of tension (evenness of the
bearing surface: è Chapter 5.1 Mechanical
installation)
Change arrangement of the payload
Align the ELFA so that it is exactly parallel to the
second axis
Modify travel speed
Return the ELFA to Festo for repair
Lubricate the ELFA (è Chapter 7 Maintenance
and care)
Return the ELFA to Festo for repair
Reduce load mass/torques
Observe max. screw-in depth
(è Chapter 5.1.2 Installation of the payload)
Check proximity switches, connections and
control
Retension the cover band
(è Chapter 7 Maintenance and care)
Replace band reverser (spare parts catalogue
è www.festo.com/spareparts)
Replace oil accumulator
