5

Installation

Pos: 114 /Technische Dokumentation/Betriebsanleitung/Installation/Einbauort/Einbauort @ 0\mod_1427869486488_370.docx @ 27047 @ 2 @ 1
5.1

Installation site

Pos: 115 /Technische Dokumentation/Betriebsanleitung/Installation/Einbauort/Aufstellfläche Multi @ 4\mod_1449224344280_370.docx @ 54692 @ 3 @ 1
5.1.1

Installation surface

 The installation surface must be level and horizontal in order
to avoid damage.
 Observe weight indications!
Pos: 116 /Technische Dokumentation/Betriebsanleitung/Installation/Einbauort/Bodenablauf muss vorhanden sein @ 0\mod_1427870166005_370.docx @ 27077 @ 3 @ 1
5.1.2

There must be ground drainage

 Calculate the size of the ground drain according to the
following criteria:
– Size of the swimming pool.
– Circulation flow rate.
Pos: 117 /Technische Dokumentation/Betriebsanleitung/Installation/Einbauort/Be- und Entlüftung Multi @ 4\mod_1449581121232_370.docx @ 55077 @ 3 @ 1
5.1.3

Ventilation and aeration

 Ensure sufficient ventilation and aeration. The ventilation and
aeration must ensure the following conditions:
– Prevention of condensation.
– Cooling of the pump motor and other system components,
for example switch cabinets and control units.
– Limitation of the ambient temperature to maximum 40 °C.
Pos: 118 /Technische Dokumentation/Betriebsanleitung/Installation/Einbauort/Körper- und Luftschallübertragung Multi @ 5\mod_1450343429616_370.docx @ 59395 @ 3 @ 1
5.1.4

Structure-borne and airborne noise transmission

 Observe regulations for structural noise protection, for
example DIN 4109.
 Install the pump in a manner which reduces structure-borne
and airborne noise transmission. Vibration-absorbing
materials are suitable bases. Examples:
– Anti-vibration buffers (Normblock Multi)
– Cork lining
– Sufficiently hard foam
Pos: 120 /Technische Dokumentation/Betriebsanleitung/Installation/Einbauort/Platzreserve Multi @ 4\mod_1449581197317_370.docx @ 55093 @ 3 @ 1
5.1.5

Reserve space

 Calculate the reserve space to allow the motor unit to be
removed in the direction of the motor fan with the help of
lifting equipment and the strainer basket to be removed from
the front.
Pos: 121 /Technische Dokumentation/Betriebsanleitung/Installation/Einbauort/Befestigungselemente @ 0\mod_1427877318034_370.docx @ 27137 @ 3 @ 1
