Transport and intermediate storage

Pos: 99 /Technische Dokumentation/Betriebsanleitung/Transport und Zwischenlagerung/Transport Multi @ 4\mod_1449224213279_370.docx @ 54644 @ 2 @ 1
4.1

Transport

 Check the delivery condition.
– Check the packaging for transport damage.
– Determine damages and contact the manufacturer and
the insurance.
NOTICE
Damage to the mechanical seal due to improper transportation.
 Protect the pump shaft against displacement during transport
with transport insurance.
Pos: 100 /Technische Dokumentation/Betriebsanleitung/Transport und Zwischenlagerung/Transport der Pumpe ohne Motor Multi @ 4\mod_1449224244481_370.docx @ 54660 @ 3 @ 1
4.1.1

Transporting the pump without the motor

The pump shaft (210) must be fixed.
 Dissemble the coupling protection (681) from the drive
lantern.
 Loosen screws (901.3).
 Push the lock washers (931) into the shaft groove.
 Tighten screws (901.3).
