Lenze 8200 vector Instructions De Montage page 98

Key for overview
Interfaces and displays
Position Description

2 light−emitting diodes (red,
green)
‚
AIF interface
(automation interface)
ƒ
FIF Iinterface
(f (function interface) i i
„
FIF II interface
(f (function interface) i i
E82EV153K4B ... E82EV303K4B
(fold−out page on the left)
Scope of supply and connections
Position Description
0
8200 vector frequency inverter
1
Fixing bracket for standard mounting
2
Blanking covers (2 pieces) for interfaces FIF I and FIF II
3
EMC shield sheet with fixing screws for shielded control cables
4
Cover with fixing screws
5
EMC shield sheet for the motor cable and for the incoming motor temperature monitoring cable
6
Label (required for mounting in accordance with UL)
T1, T2 PTC connection or thermal contact (NC contact) of the motor
U, V, W, PE Motor connection
L1, L2, L3, PE Mains connection
+U , −U DC supply
G G
X1.2 Terminal strip for connection of relay output K1
X1.3 Terminal strip for connection of relay output K2
X3.1 Terminal strip for connection of relay output K
E82EV453K4B ... E82EV553K4B
(fold−out page on the left)
Scope of supply and connections
Position Description
0
8200 vector frequency inverter
1
Fixing bracket for standard mounting
2
Blanking covers (2 pieces) for interfaces FIF I and FIF II
3
EMC shield sheet with fixing screws for shielded control cables
4
Cover with fixing screws
5
Shield clamp and strain relief for the motor cable
6
Strain relief for the protective earth cable of the motor and the incoming cable of the motor tempera-
ture monitoring with PTC thermistor (PTC) or thermal contact (NC contact)
7
Label (required for mounting in accordance with UL)
T1, T2 PTC connection or thermal contact (NC contact) of the motor
U, V, W, PE Motor connection
L1, L2, L3, PE Mains connection
+U , −U DC supply
G G
X1.2 Terminal strip for connection of relay output K1
X1.3 Terminal strip for connection of relay output K2
X3.1 Terminal strip for connection of relay output K
98
Function
Status display
Slot for communication module
e. g. E82ZBC keypad
With cover for operation without function module
f )
or slot for function module
With cover for operation without function module
f )
or slot for function module
for "safe standstill" (only for variant Bx4x)
SR
for "safe standstill" (only for variant Bx4x)
SR
l
^ 183
^ 165
^ 162
^ 120
^ 162
^ 142
^ 146
^ 119
^ 146
^ 146
^ 143
^ 155
^ 157
^ 126
^ 162
^ 142
^ 150
^ 119
^ 150
^ 150
^ 147
^ 155
^ 157
EDK82EV903 DE/EN/FR 5.1
