PARTS LIST

No. Description
1 Computer
2 Screw
3 Cover handlebar
4 End cap handlebar
5 Hand pulse sensor
6 Hand pulse cable
7 Self tapping screw
8 Handlebar
9 Self tapping screw
10 Tube spacer
11 Knob
12 Foam handlebar
13 Seat
14 Seat support
15 Washer
16 Nut
17 End cap seat support
18 Triangle part
19 Washer
20 Knob
21 Seat post
22 Seat post spacer
23 Knob
24 Sensor
25 Sensor base
26 Screw
27 Bearing
28 Washer
29 C shaped clip
30 Cover
31 Pedal (L + R)
32 Crank cover
33 Screw
34 Crank (L + R)
35 Plastic cover
36 Self tapping screw
37 Cap nut
38 Curved washer
Attention
Some of the above parts have already been assembled to the main body. These are not delivered
separately!
Qty No. Description
1 39 DC cable
4 40 Cover rear stabiliser
1 41 Rear stabiliser
2 42 Carriage bolt
2 43 Nylon nut
1 44 Axle
1 45 Nylon nut
1 46 Washer
2 47 Bracket
1 48 Spring
1 49 Washer
2 50 Carriage bolt
1 51 Carriage bolt
1 52 Cover
3 53 Flange nut
3 54 Belt
2 55 Flywheel
1 56 Conducting wire
1 57 Screw
1 58 Motor
1 59 Belt wheel
1 60 Round metal plate
1 61 Screw
1 62 Screw
1 63 Curved washer
1 64 Cover front stabiliser
4 65 Front stabiliser
2 66 Main frame
2 67 Spring washer
1 68 Allen bolt
1 69 Lower computer cable
2 70 Plastic cover
2 71 Upper computer cable
1 72 Handlebar post
2 73 Wrench
5 74 Allen wrench
4 75 Adaptor
8
24
Qty
1
2
1
4
1
1
1
1
1
1
1
1
1
2
2
1
1
1
6
1
1
1
3
6
4
2
1
1
4
4
1
1
1
1
1
1
1
