The inverter begins copying the data.
"UPDATE" and the save progress in % for the individual tests are displayed until the data
for all electronic components has been copied.
After copying the data, the inverter updates the required electronic components one after
the other.
"UPDATE," the affected component, and the update progress in % are displayed.
The inverter updates the display in the last step.
The display remains dark for approx. 1 minute, and the control and status LEDs flash.
Once the software update is complete, the inverter switches to the Startup phase and then
to grid power feed operation. The USB stick can be removed.
Individual settings in the Setup menu are retained when the inverter software is updated.
Logging Interval
Activating/deactivating the logging function, as well as setting the logging interval
Unit
Setting range
Factory setting
30 min.
20 min.
15 min.
10 min.
5 min.
No Log
IMPORTANT! The time must be set correctly in order for the logging function to work prop-
erly.

Relay

Activate Relay, Relay Settings, Relay Test
32
NOTE! To ensure problem-free updates of inverter software, the USB stick
should have no hidden partitions and no encryption (see chapter "Suitable USB
Sticks").
Save the update file to the highest data level of the USB stick
Open the data communication area
Insert the USB stick with the update file into the USB socket in the data communication
area
Go to the Setup menu and select "USB" and then "Update Software"
Press the "Enter" key
Wait until a comparison of the current software version on the inverter and the new
software version is displayed:
- 1st page: Recerbo software (LCD), key controller software (KEY), country setup
version (Set)
- 2nd page: power stage set software
Press the "Enter" key after each page
Minutes
30 min./20 min./15 min./10 min./5 min./No Log
30 min.
The logging interval is 30 minutes; new logging data is saved to
the USB stick every 30 minutes.
The logging interval is 5 minutes; new logging data is saved to
the USB stick every 5 minutes.
No data is saved
