socomec DIRIS Ap Notice D'utilisation page 58

58
AUXILIARY SUPPLY
110 to 440 V AC
120 to 350 V DC
Consumption:
Other version:
PULSE OUTPUTS
Reed relays:
N° of operations:
COMMUNICATION
RS 485:
Protocol:
Speed:
GALVANIC INSULATION (AC INSULATION VOLTAGE)
Aux. supply:
Voltage inputs:
Current inputs:
Serial link:
Pulse outputs:
OPERATING CONDITIONS
Operating temperature:
Storage temperature:
Relative humidity:
STANDARDS
Metering
CE marking
Environment:
50/60 Hz +/- 10 %
18 to 100 V DC (+/-10%)
(100 V DC - 0.5 A - 10 W)
1 or 3 wires half duplex
JBUS/MODBUS protocol / RTU mode
1400 to 38400 Bauds
-10° to + 55°C (14° to 131°F)
-20° to + 85°C (-4° to 158°F)
IEC 1036 class 1
IEC 1268 class 2
IEC 1000-4/2-3-4-5-6-8-11
SOCOMEC - Ref. : 875 510A
+/- 20 %
10 VA
< 10 8
4 kV
1.5 kV
1.5 kV
1.5 kV
1.5 kV
95 %
EN 50081-1
EN 50082-2
IEC 68-2/6-11
