Symbols Used; Technical Data - Truma Aventa comfort Instructions De Montage

Aventa comfort
Table of contents
Symbols used ........................................................................ 8
Technical data ..................................................................... 8
Installation instructions
Scope of delivery .................................................................. 9
Accessories for installation (optional) ............................. 9
Intended use .......................................................................... 9
Installation dimensions (in mm) ............................................ 9
Clearance around the air conditioning system ..................... 9
Air inlets / outlets ................................................................ 10
Condensation traps ............................................................. 10
Selecting a location ......................................................... 10
Cut-out installation 400 x 400 ....................................... 11
Installation with new cut-out ........................................ 11
Preparation for power cable connection ........................... 11
Securing the device ............................................................ 12
Use of roof thickness adapters ........................................... 12
Securing the air distributor ................................................. 12
Inserting the filters .............................................................. 13
230 V electrical connection ............................................ 13
Function check / remote control mounting ........................ 13
EN
8

Symbols used

The device must only be installed and repaired by an
expert.
Symbol indicates possible hazards.
Note containing information and tips.

Technical data

Determined on the basis of EN 14511 or Truma test conditions
Power supply
230 V - 240 V , 50 Hz
Power consumption
Cooling: 4.2 A
Heating: 3.7 A
Start-up current
28 A (150 ms)
Cooling power
2.4 kW
Heating power
1.7 kW (heat pump)
Air volume flow
max. 400 m³/h
Usage limits
+4 °C to 40 °C
Maximum angle during operation
8 %
Weight
33 kg plus installation materials
Dimensions (W x H x D)
External: 660 x 248 x 1008 mm
Internal: 523 x 46 x 670 mm
Refrigerant
R 407C / 0.67 kg
Contains fluorinated greenhouse gases covered by the
Kyoto Protocol. Hermetically sealed.
Global Warming Potential (GWP)
1774
CO2 equivalent
1188.6 kg
Subject to technical changes.
