If the welding is faulty, the message "Error" appears in the display. An acoustic and a visual sig-
nal in the form of a red flashing LED is issued.
A new data entry can be started using the >arrow to the left<.
7.4
Transfer of the stored welding protocol
Press the multi-function key >USB< on the Start screen.
The logs can be transferred from the internal memory of the device to a USB memory medium
using the "USB" menu point.
Insert a USB stick into the USB connector. Wait until the storage medium was successfully rec-
ognised. This is displayed with the respective representation. Upon actuation of the >Start< but-
ton all logs stored in the device are transferred the USB stick. The device creates a new directo-
ry with the name "ROFUSE" on the USB stick. In a sub-directory of "ROFUSE", a further directo-
ry is created with the serial number of the device as a name. The logs are stored in this directo-
ry.
The logs can be managed using the read out software RODATA 2.0 and also further processed
(see Section 9).
7.5
Configuration of the device ("SETUP")
Press the multi-function key >SETUP< on the Start screen.
The desired menu point can be selected using the two central up and down arrows and con-
firmed using the >arrow to the right<.
The >arrow to the left< allows one to leave this menu and navigate back to the Start screen.
Clock
Adjusting the date and time The date and time are displayed in the format dd.mm.yyyy hh:mm.
Select the number to be changed over the >arrow to the left< and >arrow to the right< but-
