Product description

3.1 Assemblies and functional elements
en
1 Target laser
2
Drilling table with holding magnets
3 Operating indicator
4 Opening for level controller
5
Laser warning
6 Operating key, left / right
7 Power cord with mains plug
1
2
3
8 Plate holder
9
Impression holder
10 Level controller
11 Adjusting tool for drilling depth
(screwdriver Torx T5)
12 Tool for drill fixing
(L-key Torx T10)
4
5
6
10
11
12
7
8
- 6 -
6
10
6
11
12
9
Fig. 1
