Anteria Lateral Support (Lap Belt) - Sunrise Medical zippie Simba Notice D'utilisation

6.0 Anteria Lateral Support (Lap belt)

DANGER!
Before using your wheelchair ensure the lap belt is worn.
The lap belt must be checked on a daily
basis to ensure it is free from any obstruction or adverse wear.
Always make sure that the lap belt is correctly secured and
adjusted prior to use. If the strap is too loose it could cause the user
to slip down and risk suffocation or cause serious injury.
The lap belt is fitted to the wheelchair as shown in the illustrations.
The seat belt comprises 2 halves. They are fitted using the existing
seat stay retaining bolt fitted through the eyelet on the belt. The belt
is routed under the rear of the side panel, (1). (Fig. 6.1)
Adjust the belt position so buckles are in the centre of the seat.
(Fig. 6.2)
Adjust Lap Belt To Suit The User's Needs As Follows:
To reduce the belt length
Feed free belt back through
male buckle and slide adjusters.
Ensure belt is not looped at male
buckle.
When fastened check space between the lap belt and user. When
correctly adjusted it should not be possible to insert more than the flat
of the hand between the lap belt and the user. (Fig. 6.3).
Simba
All manuals and user guides at all-guides.com
To increase the belt length
Feed free belt through slide adjusters
and male buckle to provide more belt
length.
Fig. 6.1
Fig. 6.2
Fig. 6.3
24
1
Rev.5.0
