7.0 Trouble-shooting
Wheelchair pulls to one side
• Check tyre pressure
• Check to make sure wheel turns easily (bearings, axle)
• Check the castor angle
• Check to make sure both castors are making proper
contact with the ground
Castors begin to wobble
• Check the castor angle
• Check to make sure all bolts are secure; tighten if
necessary (see the section on torque)
• Check to make sure both castors are making proper
contact with the ground.
Wheelchair / Cross-tube assembly does not snap into position
in the seat saddle
• Chair is still new, i.e., the seat or backrest upholstery is still very
stiff. This will improve with time.
Wheelchair is difficult to fold up
• Adjustable backrest upholstery is too stiff. Loosen it accordingl
Wheelchair squeaks and rattles
• Check to make sure all bolts are secure; tighten if
necessary (see the section on torque)
• Apply small amount of lubrication to spots where
movable parts come into contact with one another
Wheelchair begins to wobble
• Check angle at which castors are set
• Check tyre pressure
• Check to see if rear wheels are adjusted differently
Simba
All manuals and user guides at all-guides.com

8.0 Nameplate

Nameplate
The nameplate is located on either the cross-tube
assembly or the transverse frame tube, as well as on a
label in the owner's manual. The nameplate indicates
the exact model designation and other technical
specifications. Please provide the following pieces of
information whenever you have to order replacement
parts or to file a claim:
• Serial number
• Order number
• Month/Year
26
SAMPLE
RubiX
SIMBA
2
RubiX
SIMBA 2
Product Name/SKU Number.
Maximum safe slope with anti-tips fitted,
Depends on wheelchair setting, posture and
physical capabilities of the user.
Manufacturer Symbol
Seat Width.
Depth Maximum.
Load Maximum.
CE Mark.
User's Guide.
Crash Tested.
Date of Manufacture.
Simba XXXXXX
Serial Number.
SIMBA XXXXXX
