ADDITIONAL SAFETY ADVICE -

(3.9)
CARRYING YOUR MITRE SAW
• Although compact, this Mitre Saw is heavy.
To reduce the risk of back injury, get competent
help whenever you have to lift the saw.
• To reduce the risk of back injury, hold the tool
close to your body when lifting. Bending your
knees so you can lift with your legs, not your
back. Lift by using the handhold areas at each
side of the machines base.
• Never carry the Mitre Saw by the power cord.
Carrying the Mitre Saw by the power cord could
cause damage to the insulation or the wire
connections resulting in electric shock or fire.
• Before moving the Mitre Saw tighten the mitre
and bevel locking screws to guard against
sudden unexpected movement.
• Lock the Cutting Head in its lowest position.
Ensure that the Cutting Head Locking Pin is
completely engaged in its socket.
WARNING: Do not use the blade guard as a
'lifting point'. The power cord must be removed
from the power supply before attempting to move
the machine.
• Lock the Cutting Head in the down position
using the Cutting Head Locking Pin.
• Loosen the Mitre Angle Locking Screw. Turn the
table to either of its maximum settings.
• Lock the table in position using the Locking
Screw.
• Use the two carry handle cut-outs machined
into either side of the machine base, to transport
the machine.
Place the saw on a secure stationary work
surface and check the saw over carefully.
Check particularly the operation of all the
machines safety features before attempting to
operate the machine.
GETTING STARTED
(4.1)
UNPACKING
Caution: This packaging contains sharp objects.
Take care when unpacking. Remove the machine,
together with the accessories supplied from the
packaging. Check carefully to ensure that the
machine is in good condition and account for all
the accessories listed in this manual. Also make
sure that all the accessories are complete. If any
parts are found to be missing, the machine and its
accessories should be returned together in their
original packaging to the retailer. Do not throw
the packaging away; keep it safe throughout the
guarantee period. Dispose of the packaging in an
environmentally responsible manner.
Recycle if possible. Do not let children play with
empty plastic bags due to the risk of suffocation.
SERIAL NO. / BATCH CODE
Note: The serial number can be found on the
motor housing of the machine. For instructions on
how to identify the batch code, please contact the
Evolution Power Tools helpline or go to:
www.evolutionpowertools.com
ITEMS SUPPLIED
(4.2)
Description
Mitre Saw
Instruction Manual
RAGE Multipurpose TCT Blade
Top Hold Down Clamp
6mm Blade Change Allen Key
ADDITIONAL ACCESSORIES
(4.3)
In addition to the standard items supplied with
this machine the following accessories are also
available from the Evolution online shop at www.
evolutionpowertools.com or from your local
retailer.
(4.4)
Description
RAGE Multi-material
RAGEBLADE210MULTI
TCT Blade
Dust Bag
9
Quantity
1
1
1
1
1
Part No
030-0309
EN
