SHIPPING, SToraGE aND HaNDLING

The winder must be shipped in its original packaging and kept in the position indicated
on the packaging.
- S ize of packages (fig.1):
• width ........................................................................................................................ mm 1720
• depth ....................................................................................................................... mm 1050
• height ...................................................................................................................... mm 1450
- Weight of machine + packaging:
• PW IW three-phase 6" 8" 10" .................................................................................... 301 Kg

machine storage and shipping specifications

Temperature: -25° ÷ +55°C.
CAUTION
To avoid damage do not place other articles on top of the packaging.
To move the packing, insert the tines of a fork-lift truck into the slots on the base of the
packing itself (pallet) (fig.1).
Before moving the machine, refer to the HOISTING AND HANDLING chapter.
WARNING
Keep the original packaging; it could be useful in the future for machine transfer.

UNPaCKING / aSSEmBLY

CAUTION
Carefully carry out the unpacking, assembly, lifting and installation procedures ac-
cording to instructions provided below.
Failure to comply with these instructions could damage the machine and put the
operator at risk.
Detach the machine from the top of the pallet, check the machine for damage caused by
transport and identify the pallet mounting points (fig.1).
At this point the machine is ready for installation.
N.B. If the machine is equipped with add-on modules, refer to the section on INSTALL-
ING ADDITIONAL MODULES.
User manual PW IW 6" 8" 10"

machine shipping conditions

Handling
UK
25
