Abbreviations

All designations of the functional elements in the
operating menus depend on the configuration of the
DCU system. Standard configurations use the
following designations:

10.5.1 Process Values

Abbreviation
(TAG)
TEMP
SHAKER

10.5.2 Digital Inputs

Abbreviation
(TAG)
TEMPC
HEATC
SHAKERC
FUSEC
DCUON
SUPON
44
Meaning
Temperature on the sensor of the
heating
Shaking speed (speed of the
shaker for CERTOMAT® systems)
Meaning (and measure if
necessary)
Warning message, check required
of the Pt 1000 in the air stream
Alarm signal, short circuit of the
heating
Alarm signal, short circuit of the
shaker drive
Alarm signal, safety fuse
actuated/replace fuse
Status signal from DCU main
switch - DCU switched on
Status signal from basic device -
basic device switched on

10.5.3 Digital Outputs

Abbreviation
(TAG)
HEAT
TMPON
SHAON
Meaning (and measure if
necessary)
Status signal of the heating,
"Heating" in operation
Heating switched on
Shaker switched on
