When fitted with a correct blade this
machine can be used to cut:
Wood
Wood derived products (MDF, Chipboard,
Plywood, Blockboard, Hardboard etc)
Aluminium
Mild Steel (6mm Ø)
NOTE: Wood containing non galvanised nails
or screws can, with care, be safely cut.
PROHIBITED USE OF THIS
POWER TOOL
WARNING: This product is a Multipurpose
Sliding Mitre Saw and must only be used as
such. It must not be modified in any way,
or used to power any other equipment or
drive any other accessories other than those
mentioned in this Instruction Manual.
WARNING: This product is not intended for use
by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been
given supervision or instruction concerning the
safe use of the product by a person responsible for
their safety and who is competent in its safe use.
ELECTRICAL SAFETY
CONNECTION OF THE DOUBLE INSULATED
MAINS PLUG- UK ONLY
IMPORTANT: The wires in the mains
lead fitted to this product are coloured in
accordance with the following code:
Brown: Live (L) or Red
Blue: Neutral (N) or Black
THIS PRODUCT IS DOUBLE INSULATED
AND THEREFORE DOES NOT REQUIRE A
CONNECTION TO EARTH.
• THE 3 PIN PLUG MUST COMPLY TO
BS1363/A.
• THE FUSE MUST COMPLY TO BS1362.
6
www.evolutionpowertools.com
If for any reason the 13 amp moulded plug
fitted to this product requires replacing, the
replacement must be wired in accordance with
the following instructions:
• Connect the Blue wire to the terminal
marked Neutral (N).
• Connect the Brown wire to the terminal
marked Live (L).
Ensure that the outer insulation is gripped
by the cord grip and that the wires are not
trapped when replacing the plug cover.
A 13 amp (BS1362) fuse must be fitted in the plug.
Do not connect any wire to the earth pin
MARKED E
on the 3 pin plug.
If in any doubt consult a qualified electrician.
There are no user serviceable parts inside
this product except those referred to in the
manual. Always refer servicing to qualified
service personnel. Never remove any part of
the casing unless qualified to do so; this unit
contains dangerous voltages.
www.evolutionpowertools.com
OUTDOOR USE
WARNING: For your protection if this tool is to
be used outdoors it should not be exposed to
rain, or used in damp locations. Do not place
the tool on damp surfaces. Use a clean, dry
workbench if available. For added protection
use a residual current device (R.C.D.) that will
interrupt the supply if the leakage current to
earth exceeds 30mA for 30ms. Always check
the operation of the residual current device
(R.C.D.) before using the machine.
If an extension cable is required it must be a
suitable type for use outdoors and so labelled.
The manufacturers instructions should be
followed when using an extension cable.
POWER TOOL GENERAL
SAFETY INSTRUCTIONS
(These General Power Tool Safety Instructions
are as specified in BS EN 60745-1:2009 &
EN 61029-1:2009)
WARNING: Read all safety warnings and
instructions. Failure to follow the warnings
and instructions may result in electric
shock, fire and / or serious injury.
Save all warnings and instructions for
future reference.
The term "power tool" in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) General Power Tool Safety Warnings
[Work area safety]
• Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
• Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gasses or dust. Power
tools create sparks which may ignite the
dust or fumes.
• Keep children and bystanders away
while operating power tool. Distractions
can cause you to lose control.
7
2) General Power Tool Safety Warnings
[Electrical Safety]
• Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools.Unmodified
plugs and matching outlets will reduce the
risk of electric shock.
• Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric shock if
your body is earthed or grounded.
• Do not expose power tools to rain or wet
conditions. Water entering a power tool
will increase the risk of electric shock.
• Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the
risk of electric shock.
• When operating a power tool outdoors,
use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
• If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply. Use
of an RCD reduces the risk of electric shock.
3) General Power Tool Safety Warnings
[Personal Safety].
• Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment
of inattention while operating power tools
may result in serious personal injury.
• Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust masks, non-skid
safety shoes, hard hat or hearing protection
used for appropriate conditions will reduce
personal injuries.
