SL24.W
S1/S2/S3/S4 safety input
Off
Photocell closing (PHC)
The closing photocell:
- with the gate stopped, allows
the gate to open
- in opening does not intervene
- with the gate open, does not
allow it to close and when re-
leased will reset the pause time
- in closing, reopens the gate
immediately
Photocell (PH)
The photocell:
- with the gate stopped, does not
allow the gate to open
- during opening stops the
movement and when released
proceeds with opening
- with the gate open, does not
allow it to close and when re-
leased will reset the pause time
- in closing stops the movement
and when released reopens the
gate
Opening photocell (PHO)
The opening photocell:
- with the gate stopped, allows
S(X)
the gate to open
- in opening, recloses it completely
- with the gate open, allows it to
close and does not reset the
pause time
- in closing does not intervene
Sensitive edge with
NC clean contact (BAR)
- with the gate stopped, does not
allow the gate to open
- in opening disengages
- with the gate open, does not
allow it to close and when re-
leased will reset the pause time
- in closing disengages
8.2 KΩ balanced sensitive edge
(8K2)
Same behaviour as the NC sensi-
tive edge
Stop (STP)
- stops the gate
Interrupts the automatic closing
as per the logic stop setting from
stop (L12)
Photocell closing checked
(PHC)
As per closing photocell but with
check
Photocell checked (PHT)
As per photocell but with check
Photocell opening checked (PHC)
OFF
As per opening photocell but with
(S3 S4)
check
NC sensitive edge checked
(BART)
S(X)
As per KΩ NC sensitive edge but
with check
8.2 KΩ balanced sensitive edge
1
checked (8K2T)
(S1)
As per 8.2 KΩ sensitive edge but
with check
Control panel logic settings
Sub Description
menu
Automatic closing
L1
Automatic closing off
Automatic closing on
Pause time
1 s (minimum time)
L2
2
180 s (maximum time)
(S2)
Pedestrian pause time
1 s (minimum time)
L3
180 s (maximum time)
State on power up
Gate in closed position:
The
opens the gate.
Gate in open position:
L4
The first step-step command
closes the gate. If automatic clos-
3
ing is on, after the pause time the
gate closes
Apartment block
Apartment block function off
Does not close and stop in open-
ing
L5
Does not close and stop in open-
ing and pause
Does not close and stop in open-
ing, pause and closing
4
Rapid closing
Rapid closing function off
Rapid closing in gate mode:
The control panel starts to count
the clearance time (L7) from when
the closing photocell is released,
5
when the clearance time expires it
closes again.
Rapid closing in barrier mode:
The control panel starts to count
L6
the clearance time (L7) from
6
when the closing photocell is
released, and when the clearance
time expires it closes again. If
the closing photocell is occupied
7
again, it gives a stop command.
When released again it continues
with closing. The closing photocell
8
returns to normal operating after
complete closure.
EN
first step-step command
9
10
11
Values
(default)
(ON)
OFF
ON
(30)
1
180
(20)
1
180
(OP)
CL
OP
(OFF)
OFF
1
2
3
(OFF)
OFF
1
2
