SL24.W
- CPED
-
OPC1
LRNA
-
CLC1
- END
Self-calibration:
If the gate travel parameter is changed, there is no need
for the installer to run new calibrations, however, when
changing the travel parameters, the control panel needs
to learn the current curve again, thus disabling the obsta-
cle detection only during the self-calibration manoeuvre.
Self-calibration is appropriately signalled:
- on the control panel display by the code AT
- by the light flashing at twice the normal frequency
The events generating self-calibration are:
- change in parameters: T24, T26, T28, T30, T32, T34,
T40
- loading of settings from a MEM.W memory card
- reset/import of settings from the By-gate Pro app
Gate travel parameters
Sub Description
menu
Motor force (%).
Sets the value of the force given to
the motor to push the leaf
T1
Minimum force
Maximum force
Direction.
Sets the motor direction
Left actuator (the gate seen from
the side where the actuator is
T4
installed opens towards the left)
Right actuator (the gate seen
from the side where the actuator is
installed opens towards the right)
Choice of intervention method
for obstacle detection
Overcurrent or leaf stopped:
the obstacle is detected when the
current threshold or the encoder
slowdown threshold is exceeded
Leaf stopped: the obstacle is
detected only when the leaf slows
down excessively
T7
Overcurrent: the obstacle is de-
tected when the current threshold
is exceeded
Overcurrent and leaf stopped:
the obstacle is detected when the
current threshold and the encoder
slowdown threshold are exceeded
at the same time
16
Leaf closing from
pedestrian opening
position
Opening current
reading
Closing current
reading
End of procedure
Values
(default)
(50)
1
100
(1)
1
2
(1)
1
2
3
4
EN
Motor obstacle detection time
on opening
Time after which the current
threshold or the encoder threshold
trigger the obstacle detection on
T8
opening (adjustable at intervals of
100 ms)
100 ms (minimum time)
600 ms (maximum time)
Motor obstacle detection time
on closing
Time after which the current
threshold or the encoder threshold
trigger the obstacle detection on
T9
closing (adjustable at intervals of
100 ms)
100 ms (minimum time)
600 ms (maximum time)
Polling time
Time during which the motor
pushes with maximum force to
move the leaf (adjustable at inter-
T12
vals of 0.5 s)
0.5 s (minimum time)
5.0 s (maximum time)
Pedestrian opening position (%
of total opening travel)
T13
Minimum space
Maximum space
Disengagement space on obsta-
cle (inversion distance following
the detection of an obstacle)
T14
Not disengaged, stops only
Minimum inversion
Maximum inversion
Motor stop approach force
reduction distance
Indicates the distance from the
mechanical stop starting from
which the motor force is reduced
by half (used to adjust the impact
of the leaf on the mechanical
stop).
T15
This happens only when the con-
trol panel works with encoder and
proximity limit switch or without
limit switch.
Force reduction off
Minimum force reduction distance
Maximum force reduction distance
Easy release
Disengagement time after
manoeuvre to reduce the motor
pressure on the mechanical stop
T17
(adjustable at intervals of 100 ms)
No disengagement
100 ms (minimum disengaging)
500 ms (maximum disengaging)
(20)
10
60
(20)
10
60
(2.0)
0.5
5.0
(30)
10
100
(5)
OFF
1
10
(OFF)
OFF
10
100
(OFF)
OFF
10
50
