600 Diagnostic: Codes
GB
Status Display
9 A
1 Starla manual 2 way swivel interlock motor timed out
Starla manual 2 way swivel. Both switches activated
2
Simultaneously.
3 Starla power swivel encoder fault
Starla power swivel centred switch fault. Switch still
4
activated when encoder centred
5 Starla power swivel encoder sequence error.
6 Starla power swivel encoder incorrect sequence in travel
1 Main ECU failure
2 Option PCB failure
3 Intermittent connection between main ECU and option PCB Check connection between boards
1 Con 7 wiring loom short circuit to +24v Supply
2 Con 9 wiring loom short circuit to +24v Supply
3 Con 10 wiring loom short circuit to +24v Supply
4 Con 17 wiring loom short circuit to +24v Supply
5 Con 18 wiring loom short circuit to +24v Supply
2 Stairlift handing not specified.
3 Starla / Saxon swivel wiring incorrect.
4 New SL swivel encoder detected
F F Main ECU software failure
* If Fault Code identifies switch / wiring fault and testing the
circuit proves no fault. ECU failure should be assumed.
Resetting Encoder following a sequence fault
If Resetting the power does not clear an encoder sequence fault, this may be due to the fault occurring during an
inwards travel operation. To reset the fault use the following method:
1. Switch power 'OFF'.
2. Set switches 'F' and 'G' on SW7 on options board to the 'OFF' position. (Refer to page 9 for switch location).
3. Switch power 'ON'
4. Switch power 'OFF' and reset switches to desired configuration (Refer to page 9 for switch configuration).
5. Switch power 'ON'.
Notes on Troubleshooting

The circuits in the wiring system are split into two groups, 'A' and 'B'. The two groups use a 24V DC puls-
ing signal. The 'A' pulses are timed differently to the 'B' pulses. This aids the electronics to detect incorrect
wiring and faults.
Voltage tests should not be carried out on 'A' or 'B' circuits.
Continuity tests should only be carried out with the batteries disconnected and relevant plugs removed
from the printed circuit board. Failure to do so may result in instrument damage.

The use remote of controls to operate the stairlift is recommended when trouble shooting, in order to by-
pass chair arm and seat load switches.

When switching power on to ECU, all LED's on ECU will illuminate for approximately 1 second. This
checks operation of LEDs.

In the event of a complete power failure to the ECU, inspect 20A inline battery fuse and fuse F1 (500mA)
on main ECU.

The options board (where fitted) is supplied via fuse F2 (10A) on main ECU.
54
Fault Codes
FAULT ACTION
Check change over mechanism
Check switches / check wiring
Check encoder / connections
Check switch / encoder connections
Check / replace encoder
Refer to instruction below to repro-
gramme encoder / Replace encoder
Replace main ECU
Replace option PCB
Check wiring loom con 7
Check wiring loom con 9
Check wiring loom con 10
Check wiring loom con 17
Check wiring loom con 18
Check handing plug fitted correctly
Check chair loom con10
Replace main ECU with latest version.
Replace Main ECU
