Figure 4.4.1-4 Lateral Test Screen showing shaded threshold areas and real time data.
Figure 4.4.1-5 A right head impulse that did not meet the acceptable velocity requirements.
3D Head Modeling
A 3D head model with anatomically correct positioning and movement of the semicircular canals is
presented. It can be used as a further guide to help you determine if the head is in the correct position
and confirms which canals are being stimulated.
Figure 4.4.2-1 Head and semicircular canal model
EyeSeeCam vHIT - Instructions for Use - EN Page 21
