9.3.5 Checking the steel cables

The steel cables consist of 133 wires, and enable the telescopic column to be raised and lowered. Regularly check their condition and
that they are running perfectly inside the pulleys. Also check the tightness of the screws supporting the steel cables. At least 2 loops of
the steel cable must remain wound on the drum hoist when the column is being lowered. If this is not the case or if the steel cable has
signs of wear, do not use the lighting column, and contact the manufacturer directly.

9.3.6 Replacing the light bulbs and glasses

Close the light circuit breakers and switch off the unit before replacing any bulbs.
Allow the bulb and the frame to cool at least 45 minutes before handling.
Important
To replace a bulb, proceed as follows:
Open the light by undoing the screws (1) on the frame.
Lift the bulb mounting support by undoing the two screws. (2)
Replace the bulb.
Attach the bulb's mounting support.
Secure the light by refitting the screws.
2
The bulb used must meet the following specifications:
Bulb type: E40; metal iodide
Nominal power: 1000 W
Bulb voltage: 230V – 50 Hz
1
1
