3.3.2 Check before towing

Before towing, check the following:
Tightness of the wheels.
Locking of the hitching system.
Tyre pressure.
Closure of the set enclosure doors.
Adjustable support feet and front and rear stabilisers raised and locked.
Electrical generating set switched off.

3.3.3 Operation

The driving speed must be less than 30 km/h and adapted to the condition of the road.
Particular attention must be paid to the tightness of wheels on new vehicles, or after removing wheels. The tightness check
must be carried out whenever you have towed the trailer.
Warning

3.4. Electricity

3.4.1 People protection

The generating set must be earthed. To do this, use a minimum 25 mm
cable,connected to the generating set earth socket and a galvanised steel earthing rod fully embedded vertically into the ground.
This rod must have a minimum length as indicated in the table below.
For a default voltage of 25 V and default current of 30mA.
Nature of ground
Rich arable land,
moist compact ballast
Lean arable land,
Lean arable land,
Gravel, coarse ballast
Bare stony soils, dry sand,
impermeable rock

3.5. Special arrangements

The lighting columns are not equipped with protection devices against surges originating from atmospheric discharges or due to
manoeuvring, so it is prohibited to use the lighting column in a storm.
The company disclaims all liability for any accidents caused by these phenomena.

4. Preparation before starting the generating set supplied with the lighting column

The checks specified in this section are for ensuring proper start-up of the generating set supplied with the
lighting column.
Specific skills are required to carry out these operations.
They must only be entrusted to personnel with the necessary skills.
Failure to follow these instructions in any way could lead to incidents or very serious accidents.
Warning

4.1. Installation checks

•
make sure that the general recommendations figuring in the installation's "Instructions and safety regulations" section are
observed.
•
carry out level checks (oil, coolant, diesel, battery).
•
ensure that the generating set earth socket is earthed.
•
ensure that the electrical connections are correctly fitted.
2
Length of
rod in
metres
1
1
3.6 To obtain an equivalent length, you can use more than one
earthing rod connected in parallel and set apart by at least
their length.
Example: 4 interconnected 1 metre rods separated by
1 metre.
57/372
stripped copper wire and a 16 mm
2
for insulated
