Schematics
5.6
Electrical Schematic Components—RD 16 IRH
Ref.
Description
1
Light switch (optional)
2
Flasher
3
Turn signal switch
4
Hazard switch
5
Left turn signal light
6
Right turn signal light
7
Voltage regulator
8
Engine crank solenoid
9
Starter
10
Battery
11
Dual-function sensor
12
Oil pressure sensor
13
Air filter sensor
14
Fuel level sensor
15
20A fuse
16
30A fuse (main)
17
30A fuse (lights)
18
Horn switch
19
Vibration mode switch
20
Key switch
21
Power relay
22
Pump switch
23
Throttle switch
24
Work light switch
25
Display module
26
Pump timer module
27
Throttle solenoid
28
Glow plug engine
29
Vibration solenoid (front only)
30
Vibration solenoid (front & rear)
All manuals and user guides at all-guides.com
Ref.
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
98
Description
Brake and bypass solenoid
Reverse alarm
Fuel solenoid
Horn
Spray bar pump
Neutral relay
Crank relay
Glowplug relay
Throttle relay
Parking brake switch
Rear light (left)
Head light (left)
Head light (right)
Front parking light (left) (optional)
Front turn light (left) (optional)
Front parking light (right) (optional)
Front turn light (right) (optional)
Rear parking light (left) (optional)
Rear turn light (left) (optional)
Rear parking light (right) (optional)
Rear turn light (right) (optional)
Beacon
License light (optional)
Seat switch
Neutral switch
Vibration switch
Brake light
Brake light relay
Turn signal indicator
RD 16
