RD 16
3.4
Foldable Roll Over Protection Structure (ROPS) (if equipped)
See Graphic: wc_gr002957
WARNING
3.4.1
3.4.2
3.4.3
3.4.4
WARNING
3.4.5
3.4.6
3.4.7
3.4.8
wc_tx001075gb.fm
All manuals and user guides at all-guides.com
The machine is equipped with a Roll Over Protection Structure
(ROPS). The machine is normally delivered to the customer with the
ROPS folded forward to facilitate transport.
Do not use the machine without the ROPS in place. The ROPS is
designed to protect the operator in a rollover accident.
Before using the machine, position the ROPS in the fully upright
position as follows:
Support the upper mass ROPS using a crane and suitable rigging
capable of supporting 19 kg (42 lbs.).
NOTICE: Do not use the ROPS to lift the machine.
Remove the safety pin (a) and pull out the locking pin (b). Do so on
both sides.
Lift the ROPS into the upright position.
Insert the locking pins and secure them with the safety pins.
Be aware of pinch points when lowering and raising the ROPS.
To lower the ROPS:
Support the upper mass of the ROPS using a crane and suitable
rigging capable of supporting 19 kg (42 lbs.).
Remove the safety pin (a) and pull out the locking pin (b). Do so on
both sides.
Gently lower the upper mass.
Note: When lowering ROPS, do not allow the upper frame to fall into
the lower position. Allowing the upper mass to slam will weaken the
ROPS system and ultimately compromise its integrity and protection.
Insert the pins in the ROPS in the lower hole setting through the upper
mass to secure it for transport.
Each month, check the torque on all of the screws holding the ROPS
in place. Check that the ROPS frame is not rusty, cracked, broken, or
damaged in any way.
Keep the ROPS in the extended (upright) position when using the
roller, and always use the seat belts provided.
Change the seat belts every 3 years, or any time they have been
subjected to accident-level loads.
33
Operation
