10 ELECTRICAL DIAGRAM

EARTHING CONNECTION
WITHOUT EARTHING
NOTE:
All cables should be properly adapted to the housing provided in the plastic clad before closing the two
shells.
1.PLUG
2.SWITCH CABLE. 1.5 MM 2 SECTION
3.SWITCH CABLE. 1.5 MM
4.EARTH CABLE (green-yellow/ green -UL-)
5.CAPACITOR

11 LOCATING MALFUNCTIONS OF MOTOR

PROBLEM
The unit is not working
The motor works but it
overheats
The motor works slowly and it
overheats
The motor becomes too noisy
AVMU MOTOR - FLEXIBLE SHAFT AND POKERS
TAX1m, TAX1-5m, TAX2m, TAX3m, TAX4m, TAX5m, TAX6m
2
SECTION
1. Make sure power is on
2. Carbon brushes defect
3. Defective switch
1. Clean the frames' in and out air vents
2. Make sure nuts and bolts fixing outer box are properly fixed
1. Verify voltage of electrical system
2. Check the cable specification
3. Defective poker or shaft
1. Defective carbon brushes
2. Defective bearings
1
3. The rotor might be touching the stator
4. Outer cladding broken or has loose bolts
AVMU - AX25, AX32, AX40, AX48, AX58
6.SWITCH
7.MOTOR-SWITCH CABLE 1.5 MM 2 SECTION
8.SWITCH-MOTOR CABLE 1.5 MM
9.ESTATOR MOTOR
10. CONNECTION TO BRUSHES
CAUSE / SOLUTION
en
2
SECTION
11
